DuPont Dow Ultrafiltration (UF) Membrane Modules SFP-2880
The ultrafiltration (UF) module is made of high-strength hollow fiber membranes, which have excellent characteristics and advantages: a nominal pore size of 0.03 microns, used to remove bacteria, viruses, and particles, including colloids, to protect downstream processes. For example, reverse osmosis PVDF polymer hollow fibers have high strength and chemical resistance, making the membrane lifespan long. Hydrophilic PVDF fibers are easy to clean and wet, helping to maintain long-term performance in external flow configurations, and high resistance to feed solids, Helps to reduce the need for U-PVC shells for pre-treatment processes and eliminates the need for expensive pressure vessels.
Specification
Product parameters
l Product type: UF membrane
l Model: SFP2880 SFD2880
l Material: PVDF
l Effective membrane area ft ² （m ²）：77m ²
l housing material: U-PVC
l Recommended flux: 3.1-9.3M3/ H
Operating conditions
l Working pressure: 0.02-0.2MPa
l PH：2-11
l Maximum water inlet pressure: 6.25bar
l Operating temperature: 1-40
l Backwashing pressure:<2.5bar
l Backwash flow: 40-120L/m²/h
Operating Limits
| SI Units | US Units |
Filtrate Flux (25℃) | 40-90 I/m2//hr | 24-53 gfd |
Flow Range | 3.1-9.3 m3/hr | 13.6-40.9 gpm |
Temperature | 1-40℃ | 34-104F |
Maximum Inlet Module Pressure (20℃) | 6.25 bar | 90.65 ps |
Maximum Operating TMP | 2.1 bar | 30.5 psi |
Maximum Operating Air Scour Flow | 12 nm³/hr | 7.1 scfm |
Maximum Backwash Pressure | 2.5 bar | 36 ps |
Operating pH | 2-11 |
Maximum NaOCl | 2,000 mg/L |
Maximum Particle Size | 300μ |
Flow Configuration | Outside in,dead end flow |
Expected Filtrate Turbidity | ≤0.1 NTU |
Expected Filtrate SD | ≤2.5 |
Matters need attention
The effect of wastewater treatment depends on the input water quality, this includes: concentration, the amount of metal containing, COD, suspended particle, suspended particle, organic matter etc. Thus water analysis and membrane experimentation should be made before wastewater goes into the membrane system, besides reasonable wastewater pretreatment is also needed, unqualified wastewater is prohibited from entering into membrane components of the system, because of the high concentration organic solvent in wastewater will destroy the membrane surface and tubular membrane. Thereby blocking the membrane pores and causing water flux decline ,impact membrane system function and efficiency.
Application field
l Heavy metal removal and recovery
l Printed and dyeing wastewater treatment
l Reverse osmosis pretreatment
l Sea water desalination pretreatment
l Fluoride removal
l Wastewater processing from chemical and paper industries
l Cutting fluids recycling in silica grinding and slicing
l Lead-acid battery wastewater treatment
The wastewater goes into the membrane system cannot contain following pollutants
l Oil, grease and other oily wastewater
l The developer or developer working fluid
